HB250

We operate as a worldwide crane service provider delivering integrated one-stop lifting solutions. Backed by proven original Hyva lifting & hydraulic technology, paired with our self-owned machining, assembly and quality control production lines, we comply with international safety standards to deliver dependable complete cranes, custom refitting, spare parts and after-sales technical support for construction contractors, truck service firms and shipowners across the globe.

WhatsApp

E-mail

Product Details

6 Knuckle Boom Crane Products Core Technical Parameter Comparison Table"	Unnamed: 1	Unnamed: 2	Unnamed: 3	Unnamed: 4	Unnamed: 5	Unnamed: 6
Parameter Item	HB60	HB80	HB200	HB150	HB100	HB250
Design Standard	EN 12999/DIN 15018	EN 12999/DIN 15018	EN 12999/DIN 15018	EN 12999/DIN 15018	EN 12999/DIN 15018	EN 12999/DIN 15018
Max. net lifting moment(t·m)	6.58t.m	7.90t.m	19.30t.m	13.90t.m	9.60t.m	23.95t.m
Max Dynamic Moment	8180 daNm (8.34 T.M)	9490 daNm (9.68 T.M)	26100 daNm (26.61 T.M)	18000 daNm (18.35 T.M)	13300 daNm (13.56 T.M)	31455 daNm (32.08 T.M)
Max Rated Capacity (Min Outreach)	2630 kg at 2.5m	3160 kg at 2.5m	9000 kg at 2.15m	6500 kg at 2m	4400kg at 2.15m	9580kg at 2.55m
Max Rated Capacity (Max Outreach)	490 kg at 10.4m	590 kg at 10.45m	770 kg at 16.2m	610 kg at 14.31m	435 kg at 13.75m	965 kg at 15.92m
Max Working Pressure	245 bar	285 bar	300 bar	290 bar	290 bar	290 bar
Max Oil Flow Rate	20 l/min	20 l/min	40 l/min	25 l/min	25 l/min	50 l/min
Oil Tank Capacity	35 L	35 L	130 L	70 L	60 L	160L
Slewing Angle	387°	387°	387°	387°	395°	397°
Slewing Torque	1336 daNm (1.36 T.M)	1390 daNm (1.42 T.M)	2150 daNm (2.19 T.M)	1150 daNm (1.17 T.M)	1150 daNm (1.17 T.M)	3185 daNm (3.25 T.M)
Weight Without Stabilizers	900 kg	950 kg	1860 kg	1680 kg	1080 kg	3000 kg
Max Stabilizer Ground Pressure	3.60 MPa	3.50 MPa	3.94 MPa	4.10 MPa	4.10 MPa	3.70 MPa
Max Power Needed	10.8 kW	11.4 kW	26.0 kW	15.0 kW	15.0 kW	32.0kW
